Feature
• Spring-Piston Recoil Rated: 1000G Shockproof Rated Build Engineered for High-Power
Recoil in Airgun Shooting
• Compact 1" Monotube Design: A 25.4mm (1”) Tube Enhances Portability for Field Use
• Bright and Clear Imaging: Fully Multi-Coated Lens Delivers Optimal Light Transmission and Edge-to-Edge Clarity
• Dual-Color Illumination: 5-Level Red & Green Reticle Adapts to Different Lighting and Backgrounds
• Capped 1/10 MIL Turrets: Precise Windage & Elevation Adjustments, Scaled for Accuracy at 12x Magnification
• Comfortable Eye Relief: 4” (100mm) Eye Relief Prevents Scope Bite and Supports Proper Shooting Form
Specification
Magnification: 4-12x
Objective Lens: 40 mm
Focal Plane: Second Focal Plane
Eye Relief: 100 mm
Exit Pupil: 10-3.3 mm
Lens Coating: Fully Multi-coated
Linear Field of View @ 100 yd: 31.8-10.6 ft @ 100 yards
Linear Field of View @ 100 m: 10.6-3.5 m @ 100 meters
Angular Field of View: 6.1-1.5°
Reticle: VNM-1 MIL
Tube Dia: 25.4 mm / 1 in
Parallax Setting: 100 yards
Click Value: 1/10 MIL
Turret Function: Capped
Elevation Adjustment Range: >14.5 MIL
Windage Adjustment Range: >14.5 MIL
Diopter Compensation: +2 to -2
Illumination Setting: 5 Gears, Red and Green
Battery Type: CR2032 (NOT INCLUDE)
Waterproof: IPX4
Fogproof: Nitrogen Filled
Shockproof: 750 G
Housing Material: 6061 T6 Aluminum Alloy
Finish: Matte Black
Length: 335 mm / 13.19 in
Weight (net): 458 g / 16.15 oz
Items in the Package: User Manual, Cleaning Cloth, Flip-up Caps, Sunshade, Plastic Wrench, Power Throw Lever, etc.
Reticle
