Feature
· First Focal Plane Reticle Maintains Accurate Subtensions for Mid to Long-Range Holdovers and Ranging
· LaREE HD Lens System with FMC Optics Delivers Edge-to-Edge Clarity and Strong Low-Light Performance
· Versatile 5-30x Magnification with Side Focus from 10 Yards Adapts from Benchrest to Extended-Range Shooting
· 34mm Maintube Provides an Impressive 30 MIL Elevation Adjustment Range with Precise 1/10 MIL Click Value
· Heavy-Duty Steel Windage and Elevation Turrets Offer Crisp Tactile Feedback and Long-Term Durability
· Integrated Zero Stop System Enables Fast and Confident Return to Pre-Set Zero After Elevation Adjustments
Specification
| Specification | Details |
|---|---|
| Magnification: | 5-30x |
| Objective Lens Dia: | 56 mm |
| Focal Plane: | First Focal Plane |
| Eye Relief: | 100 mm / 3.9 in |
| Lens Coating: | Fully Multi-Coated |
| Linear Field of View @ 100 yd: | 24.0-3.9 ft @ 100 yards |
| Linear Field of View @ 100 m: | 8-1.2 m @ 100 meters |
| Angular Field of View °: | 4.6-0.7 ° |
| Reticle: | VOR-8 MIL |
| Tube Dia: | 34 mm |
| Side Focus: | 10 yards to Infinity |
| Click Value: | 1/10 MIL |
| Turret Function: | Zero Stop |
| Elevation Adjustment Range: | 30 MIL |
| Windage Adjustment Range: | 16 MIL |
| Diopter Compensation: | -2 to +2 |
| Illumination Setting: | 6 Gears, On/off Switch |
| Battery Type (Not Include): | CR2032 |
| Waterproof: | IP56 |
| Fogproof: | Nitrogen Filled |
| Shockproof: | 750 G |
| Housing Material: | 6061-T6 Aluminum Alloy |
| Turret Material: | Steel |
| Finish: | Matte Black |
| Length: | 348 mm / 13.7 in |
| Weight: | 943 g / 37.1 oz |
| Items in the Package: | Cleaning Cloth, Lens Caps, Sunshade,etc. |
