PRODUCT FEATURES
• Enhanced Mid-Range Precision: Transition from Close to Mid Range Accuracy with a 3x Red Dot Magnifier, Ideal for Hunting
• Bright Imaging: Fully Multi-coated Lens Greatly Improve Light Transmission, Presenting Edge-to-Edge Image
• Durable Rubber Armor: Provides Shock Absorption and Protection for Reliable Field Performance
• Precision Windage & Elevation Adjustment: Easy and Accurate Zeroing for Consistent Targeting
• Comfortable Shooting Position: 69mm / 2.7in Long Eye Relief Ensures a Relaxed, Safe, and Stable Shooting Experience
• Secure Picatinny Mounting: Includes SCTM-17 Flip Side Picatinny Mount, 36mm / 1.4in from Bottom to Ring Center
DESCRIPTION
Note
Match with SCRD-45, SCRD-46, SCRD-47, SCRD-12, SCRD-12II, SCRD-51, SCRD-33, SCRD-34, SCRD-26II, SCRD-04, SCRD-23, SCRD-48.
Also match with Maverick-III Red Dot Sight SCRD-38, SCRD-39, you will need to purchase the 0.83" Riser Mount (MAV-P08) for installment. Click the image to purchase.
SPECIFICATIONS
Magnification: 3x
Objective Lens Dia: 22mm
Exit Pupil: 7.0mm / 0.3in
Length: 103mm (4.1 inch)
Height: 36mm (1.4 inch, from the base to the ring center)
Weight (net):290g (10.2oz, with mount)
Eye Relief: 69mm (2.7 Inch)
Field of View (ft@100yds):49 feet
Optics Coating: Fully multi coated
Shock proof that is designed for real fire caliber
Windage and elevation can be adjust
Aluminum alloy 6061-T6 in black matte body covered with rubber
With SCTM-17 30mm flip to side picatinny mount
Fast focus eyepiece at ocular lens adjustment
With 30mm flip side mount, instruction, cleaning cloth and hex keys etc
PRODUCT DOWNLOADS
Questions & Answers
Have a Question?
-
What are the major/key feature differences between SCMF-31 and SCMF-11?
Hello, Sergey.
We have received your message.First, thanks for your consideration of our brand and products.
As for your question, SCMF-31 is rubber cover.
SCMF-31 has matched red dot in the same series.
SCMF-11 is metal.
Their appearance and volumes are different.Welcome to buy our products.
If you have other questions, welcome to contact us.
Best regards. -
Would this align with an eotech 512?
Yes, the product is compatible and would align with an EOTech 512.
-
Why do I have to buy a separate mount to use it with the Red dot of the same series Maverick gen III (SCRD-SM36)? And why if I chose the SCRD-41 the mount is not needed ? Both have the same Height: 41mm, 1.6" from bottom to center
A 0.83'' riser mount is needed to use SCRD-38/39/41/42 with the magnifier.
-
Do I need the 0.83” Riser Mount if I want to use this SCMF-31 (Maverick-III 3x22) with SCRD-SM46 (Scrapper 1x25 SOL)?
No, this will work with SCRD-SM46
-
Is the magnifier compatible with the SCRAPPER 1X22 RED DOT SIGHT?
Yes, it fits perfectly with SCRAPPER 1X22.
And here are our all red dot sights fitting this magnifier.
SCRD-45/46/47
SCRD-12/12II
SCRD-51
SCRD-33/34
SCRD-26II
SCRD-04SI/48
SCRD-23
