DESCRIPTION
Clip-On Scope Clamp Sizes:
40A = Suitable for Scopes with a 47mm-51mm Objective.
50A = Suitable for Scopes with a 55mm-59mm Objective.
60A = Suitable for Scopes with a 62mm-66mm Objective.
PRODUCT FEATURES
The CO35 1X50MM Thermal Image Scope is a device designed to help users detect and visualize heat signatures in their environment. It features a 35mm objective lens that captures thermal images, allowing users to see in complete darkness or through smoke and fog. The scope has a 1x magnification, providing a wide field of view and making it easier to spot targets. It uses thermal imaging technology to create images based on the heat signatures emitted by objects, rather than relying on visible light. This technology is particularly useful in applications such as hunting, surveillance, and search and rescue operations. The device is compact and lightweight, making it easy to handle and transport, and is built to withstand tough conditions. It also has features such as adjustable brightness, a video output, and a battery life indicator to provide users with maximum functionality and convenience.
CO50 THERMAL MODULE
50mm lens system and 640 × 512px . The matrices are built using 12 um technology.
Greater optical magnification without increasing the external dimensions of the device.
Based on VOx (vanadium oxide) technologies, with high thermal sensitivity.
Able to see the target even in extreme surveillance conditions such as snow, rain, fog/high humidity and at high ambient temperatures (from 30 degrees Celsius).
LARGE OLED DISPLAY
High resolution, 1024×768, 0.39 inch OLED, is capable of lower power consumption, wider viewing angle and richer color.
2500M DETECTION RANGE
With the advanced imaging sensor and lens, a 1.7m object can be detected from a distance up to 2500 meters.
HIGH IMAGE QUALITY
Up to 640×512 pixels and high sensitivity detector (less than 35mk NETD) gives a shaper picture of the target.
CENTRAL DISPLAY MENU
User-friendly menu selection when being assembled with the day scope.
ZEROING
Zeroing the scope by making the offset on the reticle after the first shot. 5 zeroing profiles are configurable for different distances.
MORE FEATURES TO EXPLORE
Standby mode, 8x large digital zoom, picture in picture, WIFI hotspot for mobile APP, etc. There are more to explore!
3 sensor calibration modes – automatic, semi-automatic, manual.
IMAGE MODES
SPECIFICATIONS
| Mode: VEOT-AD02 |
| Image Sensor: Uncooled Focal Plane Arrays |
| Resolution: 640 × 512 |
| Frame Rate: 50 Hz |
| Pixel Interval: 12 μm |
| Response Waveband: 8 μm to 14 μm |
| NETD: less than 35 mK (25 °C, F#=1.0) |
| Focal Length: 50 mm |
| Detaction Distance: 2600m |
| IFOV: 0.24mrad |
| Field of View: 8.78 ° × 7.03° |
| Min. Focusing Distance: 5m |
| Aperture: F1.0 |
| Magnification: 1x |
| Display: 1024×768, 0.39 inch, OLED |
| Palettes: Black hot, white hot, red hot, fusion |
| Exit Pupil: 22mm |
| Eye Relief: 10mm |
| Record Video: On-board video recording |
| Capture Snapshot: Yes |
| Standby Mode: Yes |
| Homogeneity Correction: Auto, External Correction |
| Storage Capacity: Built-in EMMC (64 GB) |
| Picture-in-Picture: Yes |
| Defect Point Correction: Yes |
| Hot Spot: Yes |
| Hot Spot Tracking: Yes |
| Cross-Line Reticle: Yes |
| Range Finding Function: No |
| Battery Type: Replaceable |
| Applicable type: CR123A, RCR123A【Not include in package】 |
| Battery Operating Time: 6.5 h (25 °C, with hotspot off) |
| Battery Capacity Display: Yes |
| Anti-reverse Battery Connection: Yes |
| Overvoltage Protection: Yes |
| Type-C Power Bank: 5 VDC, 2 A Supports external power supply |
| Work Temperature/Humidity: -20 °C to 55 °C (-4 °F to 131°F) |
| Protection Level: IP67 |
| Vibration & Shock: 750 g/1 ms |
| Dimension: 192×76×69mm |
| Weight: 583 g without eyepiece and batteries |
| Port: Type-C |
RETICLE
VIDEOS
All Super. thank you
I recently purchased a thermal imaging camera with an accompanying targeting scope for hunting, and I am blown away by how well it works. The camera picks up heat signatures from animals that are otherwise invisible to the naked eye, making it much easier to track and take down prey. The targeting scope allows me to lock onto my target with precision and accuracy, even in low light conditions. I would highly recommend this product to any serious hunter looking to up their game.
As a hunter, I've tried a lot of different tools and gadgets over the years to improve my success rate, but nothing has impressed me quite like my new thermal imaging camera. It's incredibly easy to use and provides an unparalleled level of visibility when tracking game. The targeting scope is a great addition and really helps to make accurate shots. Overall, I'm extremely satisfied with my purchase and would recommend this product to anyone who takes their hunting seriously.
If you're an outdoor enthusiast, this thermal imaging device is definitely a must-have. It allows you to see the location of animals at night, preventing potential conflicts with wildlife. I used it while hiking and found a deer hiding in the bushes. This thermal imaging device is very convenient to use and lightweight to carry. If you love outdoor activities, this product is worth buying.
Color:SCOL-15 Ships From:China
Excellent bezel, very clear and sharp, paid high tax, but worth it because the amount it
I've been using a thermal imaging camera with a targeting scope for hunting for a few months now, and I have to say, I'm thoroughly impressed. The camera is lightweight and easy to carry around, and the targeting scope is simple to adjust and use. The camera provides a clear view of heat signatures, which has made tracking game much more efficient and successful. I've even used it for spotting animals at night, which is something I never thought possible before. I highly recommend this product to anyone looking for a reliable and effective tool for hunting.
Not the first sight of this firm. Everything is as always excellent Very worthy. I personally do not see much difference with more nominal sights. It remains to see how he gives 223 rem. The set is excellent-rings, second drums (some in Moa, others in the Myla), spenek on the ring of increase, killflush, napkin, all kinds. Came by mail for a month, maybe a half.
Color:SCOL-15 Ships From:China
topp
Very responsible and attentive to their customers, about the product?? Dispenses comments!
If you're an outdoor enthusiast, this thermal imaging device is definitely a must-have. It allows you to see the location of animals at night, preventing potential conflicts with wildlife. I used it while hiking and found a deer hiding in the bushes. This thermal imaging device is very convenient to use and lightweight to carry. If you love outdoor activities, this product is worth buying.
Does it got an integrated rangefinder?
No, the OwlSet CO50 1x50mm Thermal Image Scope 3-IN-1 does not have an integrated rangefinder. It is primarily a thermal imaging device designed for riflescope, monocular, and clip-on functionality. If you need a rangefinder for distance measurements, it would need to be a separate device or an additional feature in another thermal scope model.
What is this brand name?
Owlset. It is the Vector Optics sub-brand
