Feature
Reticle
Specification
· Magnification: 4-16x
· Objective Lens Dia.: 44mm
· Ocular Lens Dia.: 38mm / 1.5 inch
· Ocular Lens Length: 60mm / 2.4 inch
· Exit Pupil: 11-2.7mm
· Optics Coating: Fully-multi coat
· Field of View: 21.1-5.3 feet@100 yds
· Eye Relief: 105--100mm / 4.1-3.9 inch
· Length: 340mm / 13.4 inch
· Weight: 650g / 23.0 ounce
· Tube Dia.: 25.4mm 1“ Monotube
· Click Value: 1/4 MOA
· Elevation Range: 50MOA
· Windage Range: 50MOA
· Parallax Setting: 10 yards to infinite
· Reticle: VOI-10BDC
· Illumination: 10 levels red+ 1 level NV
· Battery Type: CR2032
· BDC Reticle usage set at 10x power, big game, 22LR Rimfire and varmint rifles max to 600 yards range
· Distance between objective lens part and middle turret: 60mm (2.4 inch)
· Length of middle turret part: 37mm (1.5 inch)
· Distance between middle turret part to power ring: 57mm (2.2 inch)
· Side focus marks: 10, 15, 25, 50, 100, 200, 500 and infinite yds
· Shock tested to 750g and water proof
· Fully nitrogen purged to eliminate any fogging of the lenses internally
· High quality 6061 T6 aircraft grade aluminum
· Diopter compensation from fast-focus eyepiece (+2 to -2)
· Including items: weaver rings (default) or dovetail rings, flip-up caps, sunshade and cleaning cloth etc.
