Description
6x Super-Zoom Factor
Edgeless-to-Edgeless Image
Extra-Low Dispersion
30mm Monotube in Rugged Construction
Reliable Mechanics Provide Accurate MOA Clicks
Designed for M/AR & Bolt Action Platforms
Video
Realtions
Feature
· Vector Optics Top Premium Line That Can Compete Most Worldwide Famous Brand Optics
· 30mm Monotube
· Edgeless Image
· Fully Multi Coated
· >4" Long Eye Relief
· >50MOA Adjustment Range
· Wide F.O.V
· Etched Glass MOA Reticle
· 1/4 MOA Turret Lock Sys
· Illuminatated
· Lapua Magnum 338 Approved
Specification
· Magnification: 5-30x
· Objective Lens Dia.: 56mm
· Ocular Lens Dia.: 36mm (1.4 inch)
· Ocular Lens Length: 58mm (2.1 inch)
· Exit Pupil: 11.2mm-1.87mm
· Optics Coating: Fully-multi coat diamond clear
· Field of View: 19.93-3.3 Feet @ 100 yards
· Resolution: 5.5″
· Eye Relief: 124-86mm (4.9-3.4 inch)
· Length: 400mm (15.7 inch)
· Weight: 835g (29.5 ounce)
· Tube Dia.: 30mm Monotube
· Click Value: 1/4 MOA
· Elevation Range: >50MOA
· Windage Range: >50MOA
· Parallax Setting: 100 yards
· Side Focus: 20 Yds to infinite
· Reticle: Etched glass VPA-A
· Illumination: 11 gear Red
· Battery: CR2032
· Distance between objective lens part and middle turret: 55mm (2.1 inch)
· Length of middle turret part: 38mm (1.5 inch)
· Distance between middle turret part to power ring: 55mm (2.1 inch)
· MOA reticle etched glass
· Shock tested to 750g, water proof at 1m
· Fully nitrogen purged to eliminate any fogging of the lenses internally
· Turret lock system
· High quality 6061 T6 aircraft grade aluminum
· Focus mark: 20, 30, 40, 50,100, 150, 300, 600 and infinite
· Diopter compensation from fast-focus eyepiece (+2 to -2)
· Including items: 30mm picatinny high ring (default) or weaver or dovetail mount, lens caps and cleaning cloth etc.
